BEYMA CP755ND COMPRESSION DRIVERS 8 OH (P/N: 1CP755ND8)

FEATURES:

● 1,4” exit (36 mm) high frequency compression driver

● 2,85” (72,4 mm) voice coil diameter

● 160 W program power above 1,5 kHz

● Sensitivity: 110 dB (1W / 1m)

● Shorting copper cap for extended response

● Titanium dome with polyester surround

● Lightweight aluminium voice coil

● Aluminium cover

● Neodymium magnet

TECHNICAL SPECS:

Nominal diameter: 36 mm 1,4 in

Rated impedance: 8 Ω

Minimum impedance: 7,1 Ω

D.C. resistance: 5,5 Ω

Power capacity 1: 60 W (AES) above 0,8 kHz

Program power 2: 80 W (AES) above 1,5 kHz

Sensitivity 3: 110 dB 1W / 1m @ Zn coupled to TD-365

Frequency range: 0,6 – 20 kHz

Recommended crossover: 0,8 kHz or higher (12 dB/oct min.)

Voice coil diameter: 72,4 mm 2,85 in

Magnetic assembly weight: 2,7 kg 5,9 lb

Flux density: 2,2 T

BI factor: 11,5 N/A
