BEYMA 15CXA400FE LOUDSPEAKER 8 OH COAXIALS WOOFER (P/N:115CXA4FE8)

FEATURES:

*Program power: 800 / 160 W (AES) (LF/HF)

*Sensitivity: 98 / 105 dB (1W / 1m) (LF / HF)

*4″ voice coil compression driver

*Common ferrite magnet system design

*Demodulating rings in both LF and HF units

*Composite Titanium/ Polyester HF diaphragm

*Weatherproof LF cone

*60 degree coverage horn for HF dispersion control

TECHNICAL SPEC:

Nominal diameter: 380mm 15 in

Rated Impedance: (LF/HF) 8/16

Minimum Impedance: 6,3/ 11,3

Power Capacity: 400/80W

Program Power: 800/160W

Sensitivity: 98dB 1W/1m @ Zn 105dB 1W/1m @ Zn

Frequency range: 40-20.000 Hz

Recom.HF crossover 1,5 kHz or higher

Voice coil diameter: 101,6 mm 4 in

72,4 mm 2,85 in

BI factor: 18,2 N/A
