BEYMA 15LX60V2 LOUDSPEAKER 8 OH LOW AND MID FREQUENCY WOOFER (P/N:115LX60V28)

FEATURES:

● High power handling: 700 WAES

● High sensitivity: 98 dB (1W / 1m)

● FEA optimized magnetic circuit

● CONEX spider for higher resistance and consistency

● Weatherproof cone with treatment for both sides of the cone

● 4” DUO double layer in/out voice coil

● Extended controlled displacement: Xmax ± 9 mm

● 47 mm peak-to-peak excursion before damage

TECHNICAL SPECS:

Nominal diameter: 380 mm 15 in

Rated impedance: 8 Ω

Minimum impedance: 7,2 Ω

Power capacity 1: 700W (AES)

Program power 2: .400 W

Sensitivity: 2: 98dB 1W / 1m @ Zn

Frequency range: 30 – 1.500 Hz

Recom. enclosure: Vb = 125 I

(Bass-reflex design): Fb = 43 Hz

Voice coil diameter: 101,6 mm 4 in

Bl factor: 21, 1 N/A

Moving mass: 0,147 kg

Voice coil length: 20 mm

Air gap height: 10 mm

Xdamage (peak to peak): 47 mm
